Restacker NextGen

Efficient Material Handling

The Restacker increases productivity by automating stacking and batching of printed cases. Built for durability and efficiency, it handles up to 60 cases per minute, organizing them into batches for easy downstream processing.

Key Features

Restacker

  • Stacking Rate: Up to 60 cases per minute
  • Width: 48″ (1220 mm)
  • Length: 42.5″ (1080 mm)
  • Height: 50″ (1270 mm)
  • Weight: 600 lbs. (275 kg) (est.)
  • Stacking Capacities
  • Maximum Case Size: 36″ (915 mm) wide by 36″ (915 mm) long
  • Minimum Case Size: 10″ (250 mm) wide by 10″ (250 mm) long
  • Maximum Stacking Height: 12.5″ (317 mm)
  • Stacking Rate: Up to 60 cases per minute
  • Exit Height of Restacker: 17″ (430 mm
  • Sloped Stainless Steel Electrical Cabinet
  • Festo Pneumatics: Integrated with printers Cylinders, Valve Stack and Digital Filter/Regulator with adjustable sensor output
  • Integrated 24vdc Light Stack to HMI on printer
  • SEW Eurodrive Gear Motor (standard)
  • Power Requirement: 120-volt single phase, 20-amp breaker. (dedicated circuit)
  • Air Requirement: 90-psi clean shop air, 30 cfm.
